This rotary hot melt glue gun adopts 360° rotating Tef-lon glue roller structure, different from traditional jet glue guns. It performs full uniform roller coating without glue fog, no spraying pollution, and no nozzle clogging. Widely used for carton gluing, box folding and finished carton sealing in food, cosmetic, medical and packaging industries. It supports 24-hour continuous industrial operation and is perfectly compatible with semi-automatic and automatic box sealing & folder gluer machines.
Brand:
Yongtai machinePayment:
FOB XIAMENProduct Origin:
FUANJIAN,CHINAColor:
SilverShipping Port:
Xiamen PortHot melt adhesive is heated and melted by the host machine and delivered to the gun body through constant temperature heat-insulated hoses. The servo-driven Teflon roller rotates 360° continuously, carries glue evenly, and coats full-width adhesive on carton laps and sealing edges. Equipped with photoelectric automatic start-stop function, it stops gluing when no carton is detected, effectively saving glue and avoiding dripping waste. The hot melt glue cures in 1–3 seconds, providing fast and firm box bonding.
Product Advantages
No Clogging & Low Maintenance
Open roller structure without tiny nozzles, completely avoid blockage and carbonization problems of traditional jet guns.
No Glue Fog & No Box Pollution
Full roller coating without spraying, protecting printed and laminated cartons, high-end packaging zero stain.
30% Glue Consumption Saved
Precise uniform thin coating + photoelectric no-box stop glue function greatly reduces adhesive cost.
No Wrinkling for Thin Paper
Soft roller pressure, suitable for 250g–800g white cardboard, art paper and grey board boxes.
Dual-purpose for Gluing & Sealing
Suitable for folder gluer flat box forming and finished product carton back cover sealing.
Industrial Durability
Stainless steel + imported electric parts, support 24h non-stop mass production.
|
Model |
Rotary Hot Melt Coating Gun |
|
Voltage |
220V / 24V DC |
|
Heating Power |
320W |
|
Temperature Range |
120–180℃ adjustable |
|
Rotation Mode |
Servo synchronous 360° continuous rotation |
|
Applicable Glue |
EVA packaging hot melt adhesive |
|
Applicable Paper |
250g–800g white cardboard, grey board, micro corrugated box |
|
Response Speed |
0.1s automatic start-stop, no drawing glue |
|
Certification |
CE Certified |
FAQ
Can this hot melt applicator realize 360-degree rotation adjustment?
Yes. The nozzle assembly supports 360° free rotation, users can adjust the spraying angle flexibly to meet coating requirements of different workpieces.
What control mode does this applicator adopt?
It adopts pneumatic open & air close control, fast response, stable switch on and off, effectively reduce wire drawing during continuous production.
Which hot melt adhesive is suitable for this gun?
Applicable for conventional EVA hot melt glue. If you use PUR glue, customized flow channel structure is required.
What industries can this applicator be used for?
Widely used in packaging, gift box processing, composite material lamination, nonwoven fabric bonding and other production lines.
How to avoid the blockage of the flow channel?
Please use clean hot melt glue without impurities. Clean residual adhesive inside the applicator after daily production. Avoid long-time heating with leftover glue.
What is your warranty policy?
12-month warranty for main body of applicator. The nozzle tip is wearing part, which is not covered by warranty. We provide lifelong technical consultation support.
Do you support customized specifications?
Yes. We can customize spraying width, connection interface and flow channel according to customer’s production line demands.
Can it run continuously for long hours on automatic production lines?
Yes. Optimized internal runner and balanced heating structure support long-time continuous stable operation on industrial production lines.
