YT-MD502 Hot melt applicator glue dispensing machine with mini worktable

The whole system is automatic gluing process.
  • Brand:

    Yongtai machine
  • Item NO.:

    YT-MD502
  • Order(MOQ):

    1
  • Product Origin:

    Fujian,China
  • Color:

    Blue
  • Shipping Port:

    XIAMEN PORT
  • Lead Time:

    10
  • Product Detail
1. Glue bucket adopts radial heat, can segmented heating, improve the rate of sol. Glue bucket using teflon coating processing, reduces the glue carbonization rate

2. Using PID computer intelligent temperature control, Uniform heating,

3. Temperature control is accurate not be carbonized, Dual temperature protection system, safe and reliable.

4. Independent suspension gear pump, can stable output a large quantity glue.

5. Precision of automatic flow control valve can ensure the stability of the adhesive(glue), effectively improve the instant adhesive pressure unstable phenomenon.

6. Double-decked gear measurement unitized design that can adjustment two route adhesive pressure return route independently, to solve several gun glue quantity special problem on the same machine, and it can independent accurate output not disturb mutually.

7. The structure of machine adopts modular design, easy to maintenance and repair.

8. Inside with multi-layer stainless steel filter, filter impurities effectively, make output glue wheels.

9. It can select the text, the touchscreen control.



SPECIFICATIONS FOR 5KGS (L) HOT MELT GLUE MACHINE


ITEM
UNIT
YT-MD502
YT-MD501
YT-QB502
YT-QB501
Tank Capacity
Liter
5.0
5.0
5. 0
5.0
Max. malting rate
KG\HOUR
7.0
7.0
7.0
7.0
Max. Operation temp.
200
200
200
200
Melt Power
Watt
2200
2200
2200
2200
Motor power
Watt
90
90


Air pressure
KG\CM²
4-6
4-6
4-6
4-6
Dimension(L*W*H)
MM
420*380*640
420*380*640
420*380*640
420*380*640
Weigh
KG
35
35
35
35
Max. Viscosity
CPS
30,000
30,000
25,000
25,000
Power Requirement
Single Phase (1Φ), 220 V
Hose Output
Line
2
1
2
1
Pump Type

Gear pump
Gear pump
Piston pump
Piston pump
